| KARMOD BULLETPROOF ARMORED CABIN TECHNICAL SPECIFICATIONS |
| PRODUCTION DIMENSIONS |
Manufactured in various dimensions. |
| Height |
2500 mm at its highest point, including parapet. |
| Metal Materials |
ST 37 |
| Betopan |
TSE 634-2 |
| Glass Wool |
TS 901 |
| Polystyrene Foam |
TS 7316 |
| TECHNICAL DATA |
| Seismic Conditions |
1st Degree |
| Climate Conditions |
3rd Climate Zone |
| Snow Load |
200 Kg/m² |
| Wind Speed |
150 Km/h (provided that it is fixed to the ground) |
| External Wall Heat Transmission Coefficient |
K: 0.50 Kcal/m²hc |
| Roof Heat Transmission Coefficient |
K: 0.69 Kcal/m²hc |
| Floor Heat Transmission Coefficient |
K: 0.68 Kcal/m²hc |
| Chassis Load Capacity |
200 Kg/m² |
| FLOOR |
| Floor Covering |
14 mm thick non-flammable Betopan boards are used as the floor covering, with 2.5 mm thick PVC used as the flooring finish. |
| EXTERNAL WALL |
| System |
Constructed with reinforced profiles, forming a carcass structure. |
| Armor |
A strong steel construction is applied using profiles, covered with HARDOX steel (abrasion-resistant). The protection level is BR7. The total wall thickness is 100 mm. |
| Interior Surface Coating |
Over the abrasion-resistant steel, a coat of paint is applied. Water-resistant chipboard or other optional interior cladding materials can be used for aesthetic purposes. |
| Wall Insulation |
Made of 50 mm thick, 40 kg/m³ rock wool (fire class A1) providing full thermal insulation with healthy and safe materials. |
| Exterior Surface Coating |
The exterior surface is covered with 10 mm thick Stonecoat or wood-patterned Betopan boards, based on preference. |
| ROOF |
| Roof System |
Manufactured using specially shaped construction and single-piece load-bearing profiles. It is sloped to one side to prevent explosive materials from accumulating. Galvanized trapezoidal roof. |
| Roof Insulation |
80 mm thick glass wool (14 kg/m³) is used for insulation. |
| Interior Surface Coating |
PVC lamination is used for the interior ceiling. (Optional 8 mm Betopan can be used) (For WC-equipped metropolitan cabins, PVC lamination is used for the interior ceiling.) |
| Exterior Surface Coating |
The exterior surface is covered with Stonecoat patterned chipboards. |
| DOORS |
| External Door |
Made from BR7-class HARDOX abrasion-resistant steel.
Dimensions: 800x1950 mm. The door includes a 450x450 mm BR7-class viewing window. |
| WINDOWS |
Bulletproof EN 1063 BR7 NS class. The glass has a bulletproof certification from the internationally accredited laboratory TÜV Rheinland. It is scratch-resistant polycarbonate-based. The glass thickness is 85 mm and can be produced in custom sizes. |
| PAINTS |
| Exterior Facade |
The exterior surfaces are painted with silicone-based exterior paint in the desired color. |
| Door Frames |
Primed with 1 coat of rapid primer paint. |
| Metal Components |
1 coat of rapid primer paint is applied. |
| ELECTRICAL INSTALLATION (Concealed) |
| System |
The cabin includes one socket and one telephone socket. Additionally, three corners of the eaves are equipped with floodlights for lighting. |
| INSTALLATION |
Electrical power: 2000 W, 220 Volts. For sockets, 3x2.5 mm; for lighting, 2x1.5 mm TSE certified NYM cables are used. All installation materials are TSE certified. |
| OTHER |
The cabin is equipped with ventilation and exterior lighting. An emergency siren can be installed upon request to cause panic in the attacker. |
| OTHER ACCESSORIES |
| SIREN |
One emergency siren is installed to cause panic in the attacker during emergencies. |
| AIR CONDITIONER |
9000 BTU air conditioner |
| FIRE EXTINGUISHER |
One fire extinguisher is included inside the cabin. |
| LIFTING FUNCTION |
| The cabin can be lifted and lowered with lifting lugs and steel ropes from the four corners. The weight of the cabin will vary depending on its size. |
| Karmod Cabin Technologies reserves the right to make changes to the technical specifications of the product. |
